Chemical Composite Hose – 900HD PTFE
Part No.: CH-PTFE900
Colour: Purple / Yellow Stripe
Inner Wire: PVDF Coated Stainless Steel
Lining: White PVDF high wall thickness
Cover: FEP seamless tubular extruded film
Reinforcement: Polyester Fabrics
Outer Wire: Stainless Steel
Crimping: Swagged or Wire Whipped
Size Available: 3/4’’ – 12’’
Temperature: -40°C +125°C
Composite Hose – 900HD PTFE Use:
Designed for very aggressive chemicals. It is used in such applications as transfer of all the Chlorine derivates, Hydrochloric acid, Nitric and Sulphuric acid. Heavy Duty construction, can be used in general for the most arduous Industrial and Marine applications.
Applicable Standards
EN 13765:2010 TYPE 3, EN ISO 1746
Low | Med | High | |
---|---|---|---|
Flexibility | |||
Cycle Life | |||
Pressure Rating | |||
Chemical Resistance | |||
Wall Thickness |
Specifications
Safety Factor: 5:1 Standard Duty. (Burst Pressure: Working Pressure)
Download Specifications Sheet
