Hard-Wall Hoseflex® Mining Hose
Colour: Black
Tube: NR/BR blend Super Abrasion Resistant Rubber
Cover: Abrasion, UV and Ozone resistant rubber
Reinforcement: Spiral Synthetic fabric and wire helix
Size Available: DN50 to DN1200
Temperature: -30°C / + 70°C
Hard-Wall Hoseflex® Mining Hose Use:
Slurry and water transfer, dewatering and tailings pipelines as well as transfer of chemicals, hydrocarbons and acids.
| Low | Med | High | |
|---|---|---|---|
| Flexibility | |||
| Cycle Life | |||
| Pressure Rating | |||
| Chemical Resistance | |||
| Wall Thickness |
Specifications
Notes:
Bend Radius – Based on 700Kpa. Max Working Pressure – Determined by construction and fitting/flange design Lengths – Can be made up to 10 meters
Download Specifications Sheet
