VITALFLEX® Seismic Joints V Shape

Seismic Joints V Shape Use:
Used in a variety of applications and locations where subject to seismic conditions or large amounts of pipework movement. The random motion common to earthquakes requires that seismic expansion joints to be capable of movement in any direction.

Click here for Installation Guide.

Corrugated Metal Hoses: ISO 10380
AGA Approved: AS 4631:2005 (upon requirement)
Watermark Approved: WMTS 520 (upon request)
Welding Compliant: AS 4041- Class 1 (upon request)
Seismic Rated: AS 1170 (upon request)
Seismic rated: NZS 4219 – 2009 (upon request)
Fire Protection Systems (upon request)



VITALFLEX® once again leads the industry with its innovative Seismic Joints, specifically designed in a V shape to accommodate a variety of applications and locations subject to seismic conditions or significant pipework movement. In areas prone to the unpredictable motion of earthquakes, these Seismic Joints are engineered to provide unparalleled flexibility, capable of movement in any direction to absorb the random motion associated with seismic events.


1/4” (06mm) – 16’’ (500mm) (Larger sizes upon Request)


Significant cost and safety benefits found in VITALFLEX® seismic expansion joints
•    It is an inexpensive alternative to dual-tied bellows expansion joints and especially ball joints.
•    During an earthquake, it protects equipment by allowing boilers, chillers, fan-coil units and other systems to move independently from buildings such as hospitals, high rises and stadiums
•    Installation at the connection point, prevents nozzles from cracking or shearing off
•    A break in the gas pipe work could start a fire and cause vast damage to the entire building. This Australian Gas Approval (AGA) certified seismic expansion joint will compensate for the movement that occurs during any seismic activity such as an earthquake
•    Designed for potable water applications the VITALFLEX® joint can be Watermark certified in accordance with WMTS 520:2016


  • V Shape Male
  • 2
  • 3
  • L Shape
  • L Shape 2
  • Phf 1474 Side Vertical 1

Frequently Asked Questions

What size range is available for VITALFLEX® Seismic Joints?

VITALFLEX® Seismic Joints are available in a versatile size range, catering to different applications from 1/4″ to 16″.

What materials are used in the construction of VITALFLEX® Seismic Joints?

These seismic joints are crafted with high-grade materials including Inconel 625, Stainless Steel, Stainless Steel 304, and Stainless Steel 316, ensuring durability and resilience in seismic conditions.

What is the temperature range that VITALFLEX® Seismic Joints can withstand?

VITALFLEX® Seismic Joints exhibit an exceptional temperature resistance, ranging from -276°C to +700°C, making them suitable for various applications with extreme temperature variations.

Which industry standards do VITALFLEX® Seismic Joints comply with?

These joints adhere to several industry standards including AS 1170, AS 4041, AS 4631, ISO 10380, NZS 4219:2009, and WMTS 520:2016, ensuring their compliance with rigorous quality and safety benchmarks.

What is the use of VITALFLEX® Seismic Joints in a V shape?

VITALFLEX® Seismic Joints in a V shape are designed for applications where seismic conditions or significant pipework movement is common. The unique V shape enables movement in any direction, crucial for withstanding the random motion associated with earthquakes.

Can VITALFLEX® Seismic Joints be customised for specific project requirements?

Yes, VITALFLEX® Seismic Joints offer customisation options, including additional standards compliance such as Seismic Rating (AS 1170 and NZS 4219 – 2009) and Watermark Approval (WMTS 520:2016) upon request, providing tailored solutions for specific project needs.
