Chlorine Transfer PTFE
Part No.: PCTH
Construction: Convoluted
Profile: High Flexibility / Medium Pressure
Tube Available: PTFE Virgin Inner Tube with an intergal fibreglass cover
Braid Available: Two layers of Kynar reinforcement braid
Size Available: 1/2’’ – 1’’
Temperature: -70°C to 260°C
Sintered/Permeation: Slow Sintered (medium level of permeation)
Chlorine Transfer PTFE Use:
It’s the only hose that can adequately transfer chlorine in a safe manner. Exclusive design resists rugged handling and collapse.
Standards:
FDA Approved, Accepted by the U.S. Coast Guard,
PTFE Perfluorocarbon Resins meets FDA 21 CFR 177.1550
Chlorine Institute Pamphlet 6. Appendix A
Low | Med | High | |
---|---|---|---|
Flexibility | |||
Cycle Life | |||
Pressure Rating | |||
Chemical Resistance | |||
Wall Thickness |
Download Specifications Sheet
Applications
You may also like…
-
SLICKFLEX Hoseflex Smoothbore / Convoluted
Size: 1/4’’ to 2’’
Profile: Smooth / Convoluted
Temperature: -70°C to 260°C -
Convoluted Easyflex PTFE
Size : 3/8’’ to 2’’
Profile : Convoluted
Temperature: -70°C to 260°C
Related Products
-
VITALFLEX® – Annular
Size Available: 1/4’’ – 4’’
Max Temp: -276°C to 700°C -
Encapsulated PTFE SS1 Metallic Hose
Size Available: 1/2’’ – 6’’
Profile: Low Flexibility / Low Pressure
Temperature: –70°C to 260°C -
PTFE Tubing Metric
Size: 2mm – 28mm I.D.
Profile: Smoothbore
Temperature: -70°C to 260°C -
Double Diesel Expansion Joint (DDEJ)
