PTFE Ultra High Pressure Gas Cylinder Hose

PTFE Ultra High Pressure Gas Cylinder Hose Use: The PTFE Ultra High Pressure Gas Cylinder Hose is the most advanced high-pressure hose on the market. It outperforms expectations with its exceptional routability, tight bend radius, and reduced outer diameter, making it ideal for high-pressure gas and fluid applications.

Standards:
ISO 1402 – Rubber and plastic hose and assemblies – hydrostatic testing

ISO 14113 – Gas and welding equipment – Rubber and Plastic Hoses assembled for compressed and liquefied up to a maximum design pressure of 450 bar.

CGA E-9:2004 – Standard of flexible PTFE lined pigtails for
compressed gas services.

Applications: Oxygen Cylinder, Argon Cylinder, Nitrogen Cylinder, Hydrogen Cylinder, Acetylene Cylinder

Standard Lengths: 600mm, 800mm, 1200mm, 1800mm, 2400mm, 3600mm (custom lengths available)

Size: 1/4"
Material: PTFE
Temperature Range: -60°C +260°C
Profile: Smoothbore
Categories: Hoses PTFE Hoses

Information

Part No.: PTFE-UHP-SILVERSNAKE
